Personal Tracker

GPS Tracker: GTI MT90

  • Smart Design,
  • Accurate GPS Tracking
  • Weighs only 65g and is smaller than a credit card.
  • IP65 Waterproof and Rugged design.
  • Make calls like a mobile phone.
  • Simple Configuration
  • Easily attached
  • Long battery life


Sending an SMS with a Google Maps LinkGPS + GSM (LBS) Tracking, and GPS Data Recording Reports the latitude and longitude. Sends an SMS with a link for quick access to Google Maps through a smart phone. Dual-module tracking Historical report for vehicle monitoring and management Records data within 6 months every 3 minutes.

SPECIFICATIONS

Tracking On demand, time interval, distance interval Report Mileage, alarm, history, speed, parking, sensor, RFID, input, picture Alarm SOS, Geo-fence, GPS blind spot, low battery, speeding, tow, GPS antenna cut, external power cut OTA Upgrade firmware over the air

Items Specifications
Dimensions 77 x 47 x 20mm
Weight 70g
Charging Voltage MT90(V4)/MT90_S: Micro USB charging port, DC 4.2 V–5.5 V/400 mA MT90: Mini USB charging port, DC 4.2 V–5.5 V/400 mA
Standby battery 1100 mAh/3.7 V rechargeable and replaceable lithium-ion battery (Nokia BL-5C compatible)
Power Consumption MT90: 65 mA standby current and 15 mA deep sleep
Operating Temperature -20?~55?
Humidity 5%~95%
Working hour MT90(V4)/MT90_S: 240 hours in power-saving mode and 14 hours in normal mode MT90: 45 hours in power-saving mode and 14 hours in normal mode
Indicator 2 indicators showing power, GSM, and GPS status
Button/Switch 5 buttons/switches
Microphone/Speaker Internal microphone and speaker
Memory MB byte (130,000 GPS Logs, 8,000 GPRS caches, and 256 SMS caches)
Sensor Acceleration Sensor
GSM Frequency Band GSM850/900/1800/1900MHz
Positioning accuracy 10m

Click here to view the brochure.
